SIGMACOVER 280

Two component polyamide cured corrosion inhibiting epoxy primer
PRINCIPAL CHARACTERISTICS
– general purpose primer used in protective coating systems for
immersion and atmospheric exposure conditions
– good adhesion to steel and galvanized steel
– good adhesion to non ferrous metals
– good flow and wetting properties
– good water and corrosion resistance
– cures at temperatures as low as 5 °C
– suitable for touching up of weld seams and damaged epoxy
primers during construction
– long recoating intervals are possible when overcoating with
epoxy and polyurethane coatings
– can be overcoated with alkyd, chlorinated rubber, vinyl, epoxy and polyurethane coatings
– suitable for application to wet or dry abrasive cleaned substrates
– tolerant to a damp steel surface
– compatible with cathodic protection systems
– can be used in conjunction with Sigma Wet Blast Inhibitor
COLOUR AND GLOSS
red-brown and green – eggshell

Product Details
SKU: 7417 Category: Tags: ,

Basic Data At 20 °c

( For mixed product )
Mass density
approx. 1.4g/cm3
Solids content
approx. 57% by volume
Recommended
dry film thickness
50 – 125 μm
Theoretical
11.4 m2/ltr for 50 μm*
spreading rate
depending on the nature and condition of the substrate and the
application method employed
Touch dry after
approx. 30 minutes
Overcoating interval
min. 8 hours*
max. 3 – 6 months*
Full cure after
7 days*
Shelf life (cool,dry place)
12 months
Flashpoint
base and hardener – 26 °C

For immersion exposure
– steel; blast cleaned (dry or wet) to ISO Sa2½
– steel with approved zinc silicate shop primer; pretreated according to SPSS-Ss
for atmospheric exposure
– steel; pretreated to ISO-Sa2½ or ISO-St3
– shop primed steel; pretreated according to SPSS-Pt3
– galvanized steel; free from grease, salts and other contamination, preferably blast cleaned to (Rz) 30 μm
– substrate temperature should be above 5 °C and at least 3 °C above the dew point during application and curing

Mixing ratio: by volume; base to hardener 80 : 20
– the temperature of the mixed base and hardener should be above
15 °C, otherwise extra solvent may be required to obtain the
correct application viscosity
– too much solvent will result in lower sag resistance and slower cure
– thinner should only be added after proper mixing of the base and
hardener
Induction time at 20 °C
none
Potlife at 20 °C
8 hours

Method Of Application

AIRLESS SPRAY
Recommended thinner
91-92 (flashpoint 20 °C)
Volume of thinner
0 – 5% for 75 – 125 μm – 10 – 25% for 50 – 75 μm
Nozzle orifice
approx. 0.46 mm (0.018 inch)
Nozzle pressure
150 bar (approx. 2100 p.s.i.)
AIR SPRAY
Recommended thinner
91-92 (flashpoint 20 °C)
Volume of thinner
5 – 10%
Nozzle orifice
1.5 – 2.0 mm
Nozzle pressure
3 – 4 bar (approx. 43 – 57 p.s.i.)
BRUSH AND ROLLER
Recommended thinner
91-92 (flashpoint 20 °C)
Volume of thinner
0 – 5%
CLEANING SOLVENT
90-53 (flashpoint 30 °C)

Environmental

Complies with VOC specifications such as LEED etc.

Reviews

There are no reviews yet.

Be the first to review “SIGMACOVER 280”

Your email address will not be published. Required fields are marked *

About SIGMACOVER 280


Two component polyamide cured corrosion inhibiting epoxy primer
